Resistivity Controller, Case Size 48 x 96 mm, Brand HANNA USA, Input Voltage

Bl983314, 1 resistivity mini controller, 0. 00 to 19. 90 m /cm, 230veasy to handlefire retardant casingselectable overdose protection systemsplash resistant coverbl 983314 offers an uncomplicated to operate resistivity controller designed for ultra reverse osmosis, Pure water, And water conditioning applications. The bl 983314 resistivity controller serves as an excellent choice for for continuous monitoring of process solutions. Set point and calibration are manually adjusted with a trimmer and the alarm relay allows for simple control. Readings are automatically temperature compensated, With three different coefficients =2. 4, 3. 5 or 4. 5 %/ c . The alarm contact is applicable for for connection to an alarm, Pump, Solenoid or dosing system. The relay contact is open when readings are higher than the set point, While for measurements lower than set point, The relay contact is closed. The hysteresis is typically 0. 20 mw/cm from the set point. Measurements are featured on the lcd and the multicolored led continuously indicates if the controller is dosing or, In measurement alarm mode. Users can choose automatic or manual dosing mode featuring a toggle positioned up front panel. Manual control is particularly useful during because it, Maintenance operations permits operators to enable or disable the dosing relay according to need. The overtime control system advises users when the relay is active for too long, Helping to prevent over, Dosage. Specifications range0. 00 to 19. 90 m cmresolution0. 10 m cmaccuracy @25 c/77 f 2% f. S. Calibrationfactory calibrateddosing relaymaximum 2a fuse protected, 250 vac, 30 vdc contact closed when measure < setpointsetpointadjustable from 0 to 19. 90 m cmovertimeadjustable, Typically from 5 to approximately 30 minutestemperature compensationautomatic and linear from 5 Reaching as high as 50 degrees C 41 reaching as high as 122°F =2. 4, 3. 5, 4. 5 %/ c selectable through jumper on the rear panel probehi, 3314 resistivity probe with 2 m 6. 6 cable included power supplybl983314, 0 12 vdc adapter included, Bl983314, 1 115/230 vac, 50/60hzdimensions83 x 53 x 99 mm 3. 3 x 2. 1 x 3. 9 weightbl983314, 0 200 g 7. 1 oz., Bl983314, 1 300 g 10. 6 oz. Ordering informationbl983314, 0 12 vdc and bl983314, 1 115/230v are provided alongside transparent cover, Mounting brackets and instruction manual.
